Graco Ultra Max II 490 Airless Paint Sprayer - Hi-Boy

Part #: 249914

Sorry - this product is no longer available

Free shipping
(!Topic name="inc-airless-electric-v48"!)

This is the latest Hi-Boy in the 490 series. A great machine for the painting professional, serious handyman or the skilled property manager. The Ultra Max II 490 Hi-Boy has the latest technology used in the larger Ultra Max II models in this affordable, dependable unit and will out perform and outlast competitive sprayers. This is the perfect sprayer for regular use in typical painting applications.

Outfitted with the proven Graco Endurance Pump, this sprayer is built to last. These pumps feature long life V-Max Blue Packings,  a Chromex Rod and hardened stainless steel cylinder. The fluid pump features a three year overall warranty.

The Ultra Max II 490 has a brushless DC motor with enclosed design to protect internal components and has a lifetime warranty. The motor is compact, lighter than competitor models, and delivers higher horsepower per wall amp.

This 490 is equipped with SmartControl 2.0. This advanced microprocessor control delivers a consistent spray fan at all spraying pressures and a zero deadband at lower spraying pressures which makes this an ideal sprayer for fine finish work.

Equipped with a solid inlet tube for buckets or cans and wont tip cans over. It is easily removed, for cleaning or accessing inlet ball and is made of durable aluminum to be light weight and rust free.

Like the rest of the current Graco Contractor Series sprayers the 490 has an Easy Out Pump Filter which filters from the inside out so it wont collapse or get stuck when removed. Also, the filter comes out with the cap for less mess to help ease cleaning. Replacement filters are available in several mesh sizes to help fine tune your sprayer to the material you are spraying.

The NEW Graco Contractor 2-finger gun that comes with this sprayer has a in-gun filter that resides in the handle to help ensure a clean spray. Replacement filters are available in 2 mesh sizes - standard 60 mesh for most applications and 100 mesh for fine-finish work.

You simply can't go wrong with this quality sprayer made by the largest manufacturer of airless paint equipment.

Complete with Gun, Hose and Tip Box Includes:
  • 50' Hose (1/4")
  • Contractor Gun
  • RAC X Tip (517)
airless spray-painting two-story house airless spray-painting two-story house
Ultra Max II 490 Hi-Boy Specifications
0.54 Gallons per minute
1 Horse power
(Brushless DC)
RAC X Tip Type
3300 Max pressure (psi)
0.023 Max tip size (1 gun)
300 ft Max Cord Length
1/4" Hose Size
110-120 Voltage (AC)
60 Hz Voltage Frequency
Daily Usage (typical)
66 Weight
80 Shipping weight
(!Topic name="warranty-Graco-contractor"!)
