Atlas Copco SF4 AFF 5HP Oil Free Scroll Compressor with Dryer 72 Gal Tank 12.5cfm 145psi 8153613651

Atlas Copco SF4 AFF 5HP Oil Free Scroll Compressor with Dryer 72 Gal Tank 12.5cfm 145psi 8153613651

The Atlas Copco SF4 AFF is a 5hp oil free rotary scroll air compressor mounted on a 72 gallon air receiver with integrated refrigerated air dryer. Rated to displace 12.5cfm with a maximum pressure of 145psi. Operating voltage is 208/230/460v 3 phase power.

The SF4 AFF Full Feature air compressor comes with a built-in refrigerant air dryer. It cools the compressed air and removes any moisture before it can enter your air system. This prevents rust in your compressed air piping and avoids damage to your end use equipment.

The Atlas Copco SF4 AFF oil-free scroll compressor provides clean, dependable compressed air in a compact and exceptionally quiet floor-mounted package. Powered by a 5 HP IE3 TEFC motor, this air-cooled compressor delivers approximately 12.5 CFM at 145 PSI with a maximum operating pressure of 145 PSI. Its tri-voltage motor supports 208, 230, or 460-volt, three-phase power, making it adaptable to a wide range of commercial and industrial facilities.

Because oil is not introduced into the compression chamber, the SF4 delivers ISO 8573-1 Class 0 oil-free compressed air, helping eliminate the risk of oil contamination in sensitive products, processes, and pneumatic equipment. The scroll element also produces a smooth, continuous flow of pulse-free compressed air with fewer moving parts than many conventional compressor designs.

The air system is mounted on a 72 gallon air receiver tank. A sound-insulated enclosure keeps operating noise to approximately 58 dB(A), allowing the compressor to be installed closer to the point of use than many traditional industrial compressors.

Note: The model number references SF4 which is the kW rating for a 5HP motor. This SF4 does not include the Elektronikon Touch controller.

Key Features & Benefits: Atlas Copco SF4 AFF 145psi with Air Dryer and Receiver Tank / 8153613651

• Class 0 oil-free air: Protects sensitive processes from oil introduced by the compressor.
• Integrated refrigerated air dryer for moisture and water removal
• 5 HP scroll compressor: Delivers approximately 12.5 CFM at 145 PSI.
• Tri-voltage electrical configuration: Compatible with 208/230/460V, three-phase, 60 Hz power.
• IE3 TEFC motor: Premium-efficiency, totally enclosed fan-cooled motor for dependable industrial operation.
• Tank mounted on a 72 gallon air receiver tank
• Integrated aftercooler: Helps reduce compressed-air discharge temperature before air enters downstream equipment.
