Graco Ultra 395 Hi-Boy Airless Paint Sprayer - Special

Part #: 233962

Sorry - this product is no longer available

(!Topic name="inc-airless-electric-v48"!)

The Graco Ultra 395 Hi-Boy is a great machine for the professional painter, skillful handyman or the practiced property manager. The 395 uses the Graco Endurance Pump that is used throughout the Contractor Series models. This affordable, dependable easy to use compact pump is one of Graco's most popular small electric sprayer and will out perform and outlast competitive sprayers.  This is the perfect sprayer for regular use in typical painting applications.

The proven Graco Endurance Pump will spray a wide range of coatings and is built to last. These pumps feature long life V-Max Blue Packings,  a Chromex Rod and hardened stainless steel cylinder. The hammer access inlet valve makes it easy to clean and / or clear debris.

The Ultra 395 has a totally enclosed DC motor designed to protect internal components from dirt, dust, and overspray. The DC motor is more forgiving of power fluctuations because it can run at variable speeds, and also features a lifetime warranty. There is also a three year warranty on the pump/fluid section

The 395 is equipped with SmartControl 1.0. This advanced microprocessor is used in conjunction with the electronic pressure control to deliver a consistent spray fan at all spraying pressures and a tight deadband and fast response when spraying. This is a great feature to have and is highly recommended if you plan to spray any lighter viscosity paints, such as stains or lacquers.

Equipped with a solid inlet tube for 5 gallon buckets or cans and wont tip cans over. The Endurance Pump and/or inlet tube is easily removed for cleaning or accessing inlet ball and is made of durable aluminum to be light weight and rust free.

Like the rest of the current Graco Contractor Series sprayers the Ultra 395 Hi Boy has an Easy Out Pump Filter which filters from the inside out so it wont collapse or get stuck when removed. Also, the filter comes out with the cap for less mess to help ease cleaning. Replacement filters are available in several mesh sizes to help fine tune your sprayer to the material you are spraying.

The Graco NEW Graco Contractor 2-finger gun that comes with this sprayer has a in-gun filter that resides in the handle to help ensure a clean spray. Replacement filters are available in 2 mesh sizes - standard 60 mesh for most applications and 100 mesh for fine-finish work.

You simply can't go wrong with this quality sprayer made by the largest manufacturer of airless paint equipment.

Compete with gun, hose and tip

Box Includes

  • 50' Hose (1/4")
  • Contractor FTx Gun
  • RAC X Tip (515)
airless spray-painting exterior of building airless spraying exterior stucco house
Ultra 395 Hi-Boy Specifications
0.54 Gallons per minute
7/8 Horse power
(DC Motor)
3300 Max pressure (psi)
RAC X Tip type
0.023 Max tip size (1 gun)
300' Max cord length (14 Ga)
110-120 Voltage (AC)
60Hz Voltage Frequency
1/4" Hose connection sizes
Weekly Usage (typical)
1250 Gallons per year (typical)
65 Weight
84 Shipping weight
